NA 732 - Acrylic Fibre Braided Packing + PTFE Dispersion + Graphite + Oil

Synthetic fibre interlock braided packing impregnated with graphite dispersion

  • A general purpose packing with good chemical resistance and high tensile strength
  • Thorough impregnation of graphite enhances the chemical resistance and effective sealing provides trouble free start-up and low friction operation

A filament core provides mechanical strength and dimensional stability

Service Media and Conditions Water, chilled water, cooling water, solvent, mild abrasives, brine, salt water, mild acid and alkali, foodstuff etc
Temperature -100°C to 260°C
Pressure 100 bar (static), 30 bar (rotary), 20 bar (reciprocating)
Shaft Speed 12 m/sec (rotary)
pH 4 to 10
Applications Pumps and valves in pulp and paper mills
