Low Emission Packing
NA 715 - Expanded Graphite + Inconel Wire Mesh + Inconel Reinforced Braided Packing
PACMAAN® ΝΑ 715
HIGH PERFORMANCE BLOCK VALVE PACKING
An Inconel Jacheted & Multi-reinforced Expanded Graphite Gland Packing
ULTRA LOW EMISSION
- Ultra low-emission block valve gland packing certified as per api 622
- Third edition along with latest addendum - 1 for high temperature test.
CERTIFIED
- Certified as per api 589/607 fire safety standards.
AVAILABLE IN ROPE & RING FORMAT
UNIQUE METAL JACKETTED AND REINFORCED GRAPHITE PACKING
SERVICE MEDIA AND OPERATING CONDITIONSSuperheated and saturated steam, Hydrogen, All liquids and gases, Hot ash, hydrocarbons, dyes and chemicals, fuel oil and lube oil etc. |
||
TEMPERATURE240°C TO 650°C |
PRESSURE550 Bar (static) |
PH0 to 14 |
APPLICATIONS
|
INDUSTRIES SERVED |
REFINERY | POWER | CHEMICAL | STEEL | PAPER | ALUMINUM
PROVEN PERFORMANCE IN REFINERY, PETRO-CHEM, POWER & CHEMICAL PLANT, STEEL & PAPER
CASE STUDY
| VALVE 1 | VALVE 2 | VALVE 3 | |
|---|---|---|---|
| MEDIA | Hydrocarbons | Hydrogen | Superheated & Saturated steam |
| TEMPERATURE | -240°c to 650% | -240°C to 650°c | -240°c to 650°c |
| PERFORMANCE | Ultra low emission packing. Leak free performance. Increase in plant reliability. | Ultra low emission packing. Leak free performance. Increase in plant reliability. | Ultra low emission packing. Leak free performance. Increase in plant reliability |
| SAVINGS | Emission reduction across the plant. Eliminated online valve sealing. | Emission reduction across the plant. Eliminated online valve sealing. | Emission reduction across the plant. Eliminated online valve sealing. |
